IP Multicast for the Intimidated, Part 2: IGMP

August 17, 2010 Leave a Comment
x
Bookmark

ip multicastIn my last post, the first in a series about IP multicast, I tried to make the subject as painless as possible. You see, it’s been my experience that a great many network engineers get very nervous when faced with the prospect of having to work on IP multicast. Why? My guess is that it’s a matter of familiarity and practice. Familiarity is gained through education on the subject and hands-on, deliberate practice.

This post is dedicated to the Internet Group Management Protocol, or IGMP. IGMP v2 is an IETF standard defined in RFC 2236 (v3 is defined by RFC3376). When I refer to IGMP in this post, I am referring to Version 2, and I will annotate when I refer to Version 1 or 3 respectively.

Let’s start at the beginning: IGMP v1 had only two message types, a membership query and a membership report. A host would send out a membership report when it was interested in a particular group, and the router would send out a membership query when it wanted to know if hosts on the LAN were still interested in receiving a group.

This version was not able to efficiently or quickly determine when hosts on the LAN no longer wanted to receive a certain group; the router would send out membership queries for a specific group, and if there was no reply from any of the hosts after three consecutive queries, the router would stop forwarding. That’s pretty wasteful of router CPU cycles.

Since efficiency is a central them in multicast, a new version, v2, was born and set out into the world in RFC2236. Version 2 has four IGMP messages: membership query, version 1 membership report, version 2 membership report, and leave group.

The membership query message is unchanged, with the router sending out the message verifying that at least one host is still interested in each specific group. If multiple hosts on the LAN respond, the router doesn’t listen to any of the responses but the first one it receives. As long as one host is still interested, the group is active on the router.

The membership reports allow the hosts to specify which version (1 or 2) they ‘speak’. This is a backward compatibility function, since some hosts on the LAN might not have gotten the memo about the new IGMP version.

The message that comprises the biggest difference in v1 and v2 is the leave message.

In IP multicast, there are two really important messages, called joins and leaves. You will see these terms a lot, and not only in relation to the IGMP protocol, but also when looking at PIM on a router.

In IGMP v2, the addition of the leave message is in place to reduce the latency between when the last host on a LAN stops wanting to receive traffic from a specific group, to when the router stops forwarding the traffic for that group. You’ll recall that the router waits three consecutive query message cycles before discontinuing forwarding for a specific group. With the leave message, hosts on the LAN can now tell the router that they are not interested in receiving traffic from a specific group any longer. The router, in turn, sends out a group-specific membership query to the LAN, and if no other hosts respond that they still want the group traffic, the router times out the group immediately and the unwanted traffic stops being sent. That’s way more efficient, right?  I agree!

IGMP v3 is out there, but I have to be honest here in the interest of full disclosure: I have not used it or worked with it yet.

IGMP v3 adds some majorly cool functionality, in that the host on the LAN can now send a message to the router specifying not only from which group it wants to receive traffic, but also what SOURCE HOST it wants to receive that traffic from.  This is referred to as Source-Specific Multicast (SSM) and it is a really major step in the efficiency and even security of IGMP. Being able to say ‘I want that traffic from that source’ is really pretty different from the best-effort nature of IP multicast.

Again, in the interest of full disclosure, I have to admit that I have no idea about what the implementation of IGMP v3 would entail in my network, which is all IGMP v2 (and humming along nicely!).

An unfortunate default behavior of a LAN switch, after all this work to make IGMP efficient, is to flood all the ports on the same LAN with multicast traffic. That is wasteful and undesirable, and leads us to our next topic: IGMP snooping.

ip multicast

IGMP snooping requires the LAN switch to look into each multicast packet and ascertain which host on the LAN is asking to receive which group from the router. The LAN switch can then associate the host’s port to the group it is receiving traffic from. This stops the flooding of the multicast traffic to the rest of the hosts on the LAN.

Beware though: IGMP snooping is processor intensive and can easily cause severe performance issues on lower-end switches.

So, there you have the very over-simplified, high-level view of IGMP. Remember that leave messages are central to IP multicast, and that they are the main enhancement added in IGMP v2. IGMP snooping can be a good thing on a LAN switch, but can also add its own problems by taxing the switch’s resources.

As always, please lab it up if you have questions, and your mileage may vary!

See, that wasn’t so bad now, was it?

Filed Under: Configuration Tips, Featured Tagged With: , , , , , , , , ,

IP Multicast for the Intimidated: A Primer

July 30, 2010 3 Comments
x
Bookmark

ip multicastLet me ask you this: What is it about IP multicast that gives most people panic attacks?

For me, IP Multicast was scary and different than what I was used to; it is a little counterintuitive when you are used to dealing with standard IP unicast and broadcast concepts. Plus, there are a lot of new terms and concepts that come with IP multicast, and that can be overwhelming.

I’m fortunate: I happen to work in an environment where IP multicast is an integral part of a software suite that was developed in-house. The fact that IP multicast is so important to a product we support really forced me to have to learn and understand IP multicast, and specifically on Cisco infrastructure.

Since this article is designed to be a gentle introduction, I will concentrate on defining some crucial IP multicast terminology and some very general concepts of multicast.

Definition: IP Multicast

The Cisco IP Multicast Glossary has this definition of IP multicast:

  • A routing technique that allows IP traffic to be sent from one source or multiple sources and delivered to multiple destinations. Instead of sending multiple packets to each destination, a single packet is sent to a group of destinations, known as a multicast group, which is defined by a single IP destination group address.

In multicast, our source hosts, also called senders, send out a group of packets (sometimes called a stream) to a multicast group IP address. Multicast IP addresses are Class D addresses (224.0.0.0/4); there are many IPs in this range that are reserved for administrative (routing, etc) functions, but there are also IPs set aside that are like RFC 1918 addresses in the unicast world, meaning you can use them on your internal network  and not on the Internet. Different hosts on a network within your administrative control (your LAN) can subscribe to the group IP to receive the content that is being sent from the source host.  Unlike IP broadcast, which is ‘one-to-all’ whether a host wishes to receive traffic or not, IP multicast protocols allow hosts to selectively receive the traffic they want, and hosts that don’t want that traffic don’t get it.

Definition: IGMP

IGMP, the Internet Group Management Protocol (originally specified in RFC 1112), is a standards-based protocol that provides a protocol for hosts on a LAN to tell their local router that they want to receive certain IP multicast group traffic. The point of IGMP was and is to allow hosts to dynamically register to receive the desired multicast traffic.

There are three versions of IGMP, appropriately named version 1, 2 and 3. Each version has characteristics that I will attempt to cover in future articles. The key point to remember here is that IGMP is how a host on your LAN tells its router that it wants to receive a certain multicast group.

Definition: PIM

Protocol Independent Multicast, PIM, is the multicast routing protocol that allows existing IP networks to route IP multicast, regardless of what unicast routing protocol is in use. You could be using EIGRP, OSPF, ISIS, even iBGP; PIM was designed to work over any existing IP routing protocol (thus the name ‘Protocol Independent’). PIM is designed to use the existing routing tables as provided by the unicast routing protocol to make its multicast routing decisions.

PIM was defined by the Internet Engineering Task Force and is an open standard. Since I have not worked with PIM on any platform other than Cisco, I won’t attempt to cover differences in implementation.

PIM has two typical modes of operation: Sparse and Dense. It’s difficult to really explain these well in a few words, so I will only say this: Dense mode floods traffic out until other routers tell it to stop, while Sparse mode only sends traffic when specifically requested. It’s an oversimplification, but think of Dense=more, Sparse=less.

Key Points Summary

We know that IGMP deals with multicast-enabled hosts on a LAN communicating with their router. IGMP=Host and Router. There are three versions of the IGMP protocol, with v2 being most prevalent, and v3 up and coming.

PIM deals with router-to-router communication. PIM relies on the underlying routing protocol (OSPF, EIGRP, etc) to be able to make its multicast routing happen. PIM=Router-to-Router.

Tune in Next Time

That is all for this installment. The next article will deal with IGMP and IGMP snooping more in-depth. After that, we’ll venture up the OSI stack and have a detailed look at PIM, SM and DM respectively.

For the most comprehensive IP Multicast for Cisco reference, look to Beau Williamson’s ‘Developing IP Multicast Networks, Volume 1’ from Cisco Press. It is absolutely required reading for the aspiring CCIE. If you have Cisco CCO access, locate the ‘Internetworking Technology Handbook’ and read the IP Multicast Chapter.

Filed Under: Featured, Routing, Switching Tagged With: , , , , , , ,
